Routers: Transmitting Packets
What is packet transmission? Packet transmission across networks relies on routers to securely break down digital messages into smaller bytes of data called packets. These routers scan each packet for an IP address and forward it along the most efficient available pathway, reassembling the data once it reaches its final destination.
When you make a telephone call to someone on the other side of the country, the telephone system establishes a stable circuit between your telephone and the telephone you're calling. The circuit might involve a half dozen or more steps through copper cables, switches, fiber optics, microwaves and satellites, but those steps are established and remain constant for the duration of the call. This circuit approach means that the quality of the line between you and the person you're calling is consistent throughout the call, but a problem with any portion of the circuit -- maybe a tree falls across one of the lines used, or there's a power problem with a switch -- brings your call to an early and abrupt end. When you send an e-mail message with an attachment to the other side of the country, a very different process is used.
Internet data, whether in the form of a Web page, a downloaded file or an e-mail message, travels over a system known as a packet-switching network. In this system, the data in a message or file is broken up into packages about 1,500 bytes long. Each of these packages gets a wrapper that includes information on the sender's address, the receiver's address, the package's place in the entire message, and how the receiving computer can be sure that the package arrived intact. Each data package, called a packet, is then sent off to its destination via the best available route -- a route that might be taken by all the other packets in the message or by none of the other packets in the message. This might seem very complicated compared to the circuit approach used by the telephone system, but in a network designed for data there are two huge advantages to the packet-switching plan.
- The network can balance the load across various pieces of equipment on a millisecond-by-millisecond basis.
- If there is a problem with one piece of equipment in the network while a message is being transferred, packets can be routed around the problem, ensuring the delivery of the entire message.
The Path of a Packet
The routers that make up the main part of the Internet can reconfigure the paths that packets take because they look at the information surrounding the data packet, and they tell each other about line conditions, such as delays in receiving and sending data and traffic on various pieces of the network. Not all routers do so many jobs, however. Routers come in different sizes. For example:
- If you have enabled Internet connection sharing between two Windows 98-based computers, you're using one of the computers (the computer with the Internet connection) as a simple router. In this instance, the router does so little -- simply looking at data to see whether it's intended for one computer or the other -- that it can operate in the background of the system without significantly affecting the other programs you might be running.
- Slightly larger routers, the sort used to connect a small office network to the Internet, will do a bit more. These routers frequently enforce rules concerning security for the office network (trying to secure the network from certain attacks). They handle enough traffic that they're generally stand-alone devices rather than software running on a server.
- The largest routers, those used to handle data at the major traffic points on the Internet, handle millions of data packets every second and work to configure the network most efficiently. These routers are large stand-alone systems that have far more in common with supercomputers than with your office server.
Routing Packets: An Example
Let's take a look at a medium-sized router -- the router we use in the HowStuffWorks office. In our case, the router only has two networks to worry about: The office network, with about 50 computers and devices, and the Internet. The office network connects to the router through an Ethernet connection, specifically a 100 base-T connection (100 base-T means that the connection is 100 megabits per second, and uses a twisted-pair cable like an 8-wire version of the cable that connects your telephone to the wall jack). There are two connections between the router and our ISP (Internet service provider). One is a T-1 connection that supports 1.5 megabits per second. The other is an ISDN line that supports 128 kilobits per second. The configuration table in the router tells it that all out-bound packets are to use the T-1 line, unless it's unavailable for some reason (perhaps a backhoe digs up the cable). If it can't be used, then outbound traffic goes on the ISDN line. This way, the ISDN line is held as "insurance" against a problem with the faster T-1 connection, and no action by a staff member is required to make the switch in case of trouble. The router's configuration table knows what to do.
In addition to routing packets from one point to another, the HowStuffWorks router has rules limiting how computers from outside the network can connect to computers inside the network, how the HowStuffWorks network appears to the outside world, and other security functions. While most companies also have a special piece of hardware or software called a firewall to enforce security, the rules in a router's configuration table are important to keeping a company's (or family's) network secure.
One of the crucial tasks for any router is knowing when a packet of information stays on its local network. For this, it uses a mechanism called a subnet mask. The subnet mask looks like an IP address and usually reads "255.255.255.0." This tells the router that all messages with the sender and receiver having an address sharing the first three groups of numbers are on the same network, and shouldn't be sent out to another network. Here's an example: The computer at address 15.57.31.40 sends a request to the computer at 15.57.31.52. The router, which sees all the packets, matches the first three groups in the address of both sender and receiver (15.57.31), and keeps the packet on the local network. (You'll learn more about how the addresses work in the next section.)
Between the time these words left the Howstuffworks.com server and the time they showed up on your monitor, they passed through several routers (it's impossible to know ahead of time exactly how many "several" might be) that helped them along the way. It's very similar to the process that gets a postal letter from your mailbox to the mailbox of a friend, with routers taking the place of the mail sorters and handlers along the way.
