Introduction to FTA Satellite TV

A while ago, I posted a guide on how to receive Don't Panic TV, which was a channel broadcasting adult programming to Southern Africa off PAS7/10. It was interesting because when they weren't broadcasting shows, their encryption was off, and you could see their advertising card, along with a couple of Italian music channels. However, Don't Panic TV is no more.

Fortunately, there are still a couple of completely free-to-air (FTA) Ku-band channels available off PAS7/10 in South Africa. As of this documentation, you can tune your decoder to access various regional, educational, and entertainment broadcasts without paying a monthly premium subscription. Please verify with satellite frequency tracking platforms for the absolute latest transponder details.

Comprehensive List of Available Channels

Below is a detailed breakdown of the free-to-air and partially encrypted channels available. These services cover a wide range of genres, from education to general entertainment.

Sentech Vivid Bouquet

• SEN1-6: Includes Mindset Network channel 1 (dedicated to education) and channel 2 (focused on health), as well as Jet TV.
• PTV1-6: Please note that some of these are Nagravision-encrypted.
• SABC1/2/3 and e.tv: Typically Nagravision-encrypted and require a subscription or specific smart card authorization.
• Religious Networks: LCN, Hope, Ps91, ITV, DTBC, God Channel, TCT, and DayStar (mostly free-to-air).
• Guide Channel: Interactive channel that may not fully function on all third-party decoders.
• Audio Broadcasts: Several free-to-air radio stations are also bundled within this transponder.

Botswana TV (BTV)

• BTV: A reliable free-to-air general entertainment channel originating from Botswana. It features multiple audio tracks that function similarly to independent radio stations.

Fashion TV and Lifestyle

• FTV: Fashion TV is broadcast entirely free-to-air, showcasing global fashion and lifestyle content.

ManaSat Network

• ManaSat 1: Religious programming, free-to-air, broadcast in Portuguese with two secondary audio tracks.
• ManaSat 2: Religious programming, sometimes encrypted depending on the broadcasting schedule, Portuguese language.

Novacom Transponder Services

• Testing Services: Novacom test card.
• Religious Programming: DayStar, LoveWorld, and God Channel (free-to-air).
• International and Niche: RTNC, APNA, BEStv, and Extreme Sports (all broadcasting free-to-air).

Step-by-Step Decoder Configuration Directions

I have compiled all the functional network settings below along with their appropriate tuning parameters. Follow these directions carefully. If your decoder interface differs, look for similar terminology in your manual.

1. Using your remote control, press the MENU button.
2. Navigate to ADVANCED OPTIONS and press OK.
3. Select LNB CONFIGURATION and press OK.
4. Choose LNB 1 SETUP and press OK.
5. Verify that the LNB HI FREQUENCY is set to exactly 10700. If it is different, change it to 10700, and select ACCEPT THESE SETTINGS.
6. Press the EXIT button.
7. Navigate to DISH INSTALLATION and press OK.
8. When prompted, enter the default installation PIN number (often 9949, 0000, or 1234 depending on your hardware).
9. Select NETWORK CONFIGURATION and press OK.
10. Input the network setup details provided in the next section. Select each network setup slot and enter the precise frequencies.

Important Note: The first option is usually your home network (like DStv). You should not alter your home network settings. At each step, you may select "VIEW SIGNAL STRENGTH" to confirm that the transponder signal is valid for your dish alignment. Once confirmed, select "ACCEPT THESE SETTINGS".

Technical Network Setup Details

Input these precise parameters to lock onto the respective satellite bouquets.

Network 1: Home Network (Reference Only)

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 10970
• Symbol Rate: 30000
• Polarisation: Vertical
• FEC: 5/6

Network 2: Sentech Vivid Bouquet

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 11170
• Symbol Rate: 266652 (or 26665)
• Polarisation: Vertical
• FEC: 5/6

Network 3: BTV Network

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 11625
• Symbol Rate: 15000
• Polarisation: Vertical
• FEC: 2/3

Network 4: Fashion TV (FTV)

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 12722
• Symbol Rate: 26657
• Polarisation: Horizontal
• FEC: 2/3

Network 5: ManaSat

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 12577
• Symbol Rate: 3378
• Polarisation: Vertical
• FEC: 3/4

Network 6: Novacom Bouquet

• Signal Setup: Enabled
• Orbital Position: PAS7/10
• Use NIT: Yes
• Frequency: 12682
• Symbol Rate: 26657
• Polarisation: Horizontal
• FEC: 1/2

Scanning Procedures and Final Steps

Once you have inputted the frequencies, you must initiate a network scan to populate your channel list.

1. Press EXIT and return to the DISH INSTALLATION menu.
2. Select SCAN ALL NETWORKS.
3. Your decoder will attempt to lock onto the transponders and register all active channels.
4. Once tuning is complete and the interface returns to normal viewing mode, press the TV button to bring up the bouquet list.
5. Select the "Public PAS7/10" option.
6. You can now navigate the public TV bouquet. Channels will appear sequentially based on your network setups (Sentech, BTV, FTV, ManaSat, Novacom).
7. Pressing the AUDIO button on your remote will switch to the public audio bouquet, allowing you to tune into various regional radio broadcasts.

Troubleshooting and Disclaimer Notes

Keep these critical points in mind when attempting to access FTA networks on PAS7/10:

• Some listed channels may become encrypted without warning. Broadcasters frequently change their encryption policies.
• While there is free content available, premium high-definition entertainment typically requires a paid subscription service.
• Your specific dish installation, LNB type, or geographic footprint may prevent you from locking onto these signals.
• It is recommended to perform these setups while actively tuned to a decrypted home channel. Ensure your smart card remains inserted during the process.
• If your decoder requires a 4-digit symbol rate and you have a 5-digit number, you might need to drop the last digit or consult your hardware manual.
• Disclaimer: These technical settings are provided for informational purposes only. If they fail to work on your specific hardware, or if you accidentally corrupt your decoder's configuration, you will need to perform a factory reset. The author assumes no liability for configuration errors.

Frequently Asked Questions

For further clarity on satellite television reception, please review these common inquiries.

What free-to-air channels are available on PAS7/10 in South Africa?

Several channels are available including the Sentech Vivid bouquet (Mindset Network, Jet TV, religious channels), Botswana TV (BTV), Fashion TV (FTV), ManaSat, and Novacom. Some SABC and e.tv channels might be encrypted.

How do I configure my decoder for Sentech Vivid on PAS7/10?

You need to access your decoder's network setup and enter: Frequency 11170, Symbol Rate 266652 (or equivalent 4-digit), Vertical Polarisation, and FEC 5/6. Ensure your LNB HI FREQUENCY is set to 10700.

Why are some channels on PAS7/10 encrypted?

Broadcasters encrypt premium content or channels intended only for specific paid subscriptions (like DStv). Free-to-air channels are transmitted without encryption and can be viewed with any standard Ku-band decoder.
